Range : O2 : 1 ppb to 12 ppm & CO2 : 0.75 to 5 v/v or 1.5 to 10 g/kg
Repeatability (r95) :
TPO : ±5 μg/L ±10 %, whichever the greater
CO2 : ±0.05 v/v or 0.10 g/kg ±2 %, whichever is greater, measured on equilibrated packages at 10 to 25 °C
Typical analysis time : Approximately 4 minutes
Units :
O2 concentration : ppb, ppm
CO2 concentration : v/v, g/kg, g/L %W
Total package quantities : mg, mL, mg/L,mL/L, μg/L
Pressure : bar, mbar, psi
Temperature : °F, °C, K
Operating conditions :
Package temperature : -2 to 30 °C (28 to 86 °F)
Package pressure : 1.4 to 6.8 bar (20 to 73 psi)
Ambient temperature : 0 to 40 °C (32 to 104 °F)
Package settings :
Closure types : metallic, PET
Package height : min. 90 mm (3.54 in.) & max. 340 mm (13.39 in.)
Package volume : min. 150 mL
Enclosure rating : IP20
Compliance :
European directives : Low voltage
2006/95/EC; EMC 2004/108/EC
Electromagnetic compatibility standards : EN61326
Safety standard : IEC/UL/CSA 61010-1
Safety of laser products : IEC/UL/CSA 60825-1
Display type : Digital TFT VGA (640 x 480) color touch screen
Communication capabilities : 1 x USB client, 1 x USB host, 1 x Ethernet
Installation requirement :
Power requirements : 100/240 VAC, 50/60 Hz
Purge gas : CO2 with purity >99.9% at 6 to 7 bar abs (87 to 102 psi)
Dimensions (H x W x D) : 942 mm x 540 mm x 537 mm
Weight : 121.25 lbs. (55 kg)
