Range
Low Range : g/100 mL as citric acid: 0.10 to 2.00% CA; g/100 mL as tartaric acid: 0.11 to 2.35% TA; g/100 mL as malic acid: 0.10 to 2.09% MA
High Range : g/100 mL as citric acid: 1.00 to 10.00% CA; g/100 mL as tartaric acid: 1.17 to 11.72% TA; g/100 mL as malic acid: 1.05 to 10.47% MA
Resolution : 0.01%
Accuracy (@25ºC/77ºF) : ±0.02% or 3% of reading CA whichever is greater
Sample Volume : Low Range: 5 mL High Range: 5 mL
Methods : acid base titration
Principle : endpoint titration: 8.1 pH
Pump Speed : 10 mL/min
Stirring Speed : 600 rpm
pH Range : -2.0 to 16.0 pH; -2.00 to 16.00 pH
pH Accuracy (@25ºC/77ºF) : ±0.01 pH
mV Range : -2000.0 to 2000.0 mV
mV Resolution : 0.1 mV
mV Accuracy (@25ºC/77ºF) : ±1.0 mV
Temperature Range : -20.0 to 120.0°C; -4.0 to 248.0°F; 253.2 to 393.2 K
Temperature Resolution : 0.1°C; 0.1°F; 0.1K
Temperature Accuracy (@25ºC/77ºF) : ±0.4°C; ±0.8°F; ±0.4 K
Logging Data : up to 400 ( 200 titrations, 200 pH/mV readings)
Environment : 0 to 50°C (32 to 122°F); RH max 95% non-condensing
Power Supply : 12 VDC adapter (included)
Dimensions : 235 x 200 x 150 mm (9.2 x 7.9 x 5.9”)
Weight : 1.9 kg (67.0 oz.)
