Sampling method : Suction type
Principle of detection : Non-Dispersive Infrared Method, Potentiostatic Electrolysis Method, Membrane Type Galvanic Cell Method
Detection range :
0 to 100.0 %LEL / 2 to 100.0 vol% (HC)
0 to 40.0 vol% (0 to 25.0 vol%) (O2)
0 to 100.0 ppm (0 to 30.0 ppm) [Low](H2S)
0 to 1000 ppm [High](H2S)
Type of alarm : Gas alarm / fault alarm
Display of alarm : Lamp blinking / buzzer / detail display
Explosion protected construction : Intrinsic safety
Explosion-proof class :
IECEx : Ex ia IIC T4 Ga
ATEX : II1G Ex ia IIC T4 Ga
Ingress proof rating : IP67
Approvals : Japan Ex, ATEX, IECEx, Brazil Ex, MED, JG, NK, ABS
CE marking : EMC / ATEX / RoHS
Power source : Lithium ion battery unit or Dry battery unit (AA alkaline battery 3pcs.)
Continuous operation :
Approx. 15 hours [Lithium ion battery unit]
Approx. 8 hours [Dry battery unit]
Operating temperature range : -20 to 50℃ (no sudden changes)
Operating humidity range : 0 to 95 %RH (no condensing)
Dimensions : Approx. 154 (W) × 81 (H) × 163 (D) mm (excluding projections)
Weight : Approx. 1.3 kg [Lithium ion battery unit]
