Temperature (flue gas) : -40 to +1200 °C
Draught measurement : -9.99 to +40 hPa
Pressure measurement : 0 to +300 hPa
O2 measurement : 0 to 21 Vol. %
CO measurement (without H2-compensation) : 0 to 4000 ppm
CO measurement (H2-compensated) : 0 to 8000 ppm
Determination of degree of effectivity (Eta) : 0 to 120%
Flue gas loss : 0 to 99.9%
Ambient CO measurement (with CO probe) : 0 to 500 ppm
Gas leak measurement for combustible gases (with gas leak detection probe) : Display range 0 to 10.000 ppm CH4/C3H8
Ambient CO2 measurement (with ambient CO2 probe) : 0 to 1 Vol. % & 0 to 10.000 ppm
NO low : 0 to 300 ppm
Differential pressure, flow velocity and temperature via fine pressure probe : ±10.000 Pa & 0.15 to 3 m/s, max. -40 to +1,200 °C (dependent on probe)
Storage temperature : -20 to +50 °C
Operating temperature : -5 to +45 °C
Power supply Battery : Rechargeable battery pack 3.7 V / 2.6 Ah & Mains unit 6 V / 1.2 A
Memory : 500.000 measurement values
Weight : 600 g (without rechargeable battery)
Dimensions : 270 x 90 x 65 mm
